The TomoScope® FQ family of instruments allows the calculation and evaluation of the measurement point cloud to be accelerated by up to 50 times. For workpieces such as valve blocks, housings and castings, the geometrical characteristics can be determined almost every half minute, a nominal-actual comparison with the measuring point cloud of a master part can be carried out and the workpieces can be tested for defects such as burrs. The WinWerth® Scout measurement software offers a clear status display for run-out and completed measuring processes and access to all measurement results at the click of a mouse.

All TomoScope® measuring machines are available as "FQ" version

Maintenance-free closed high-performance X-ray tube for fast measurement of dense materials and large workpieces

Integrated shutter to avoid time-consuming switching on and off of the tube with extended lifetime

High-end detector for high-performance measurement with fast image acquisition in OnTheFly mode

Workpiece feeding with robot through front door or upper loading opening

Remote programming at offline workstations

Start of the measuring process via QR code or RFID chip for clear identification of workpieces and batches

Task sharing between computed tomography and multi-sensor coordinate measuring machines

Type

3D CNC coordinate measuring machine with computed tomography sensors

Measuring range

Max. Workpiece dimensions D = 470 mm / L = 678 mm (depending on the aspect ratio of the workpieces)

Accuracy

Permissible probing error up to 4.5 µm

The universal measurement software for coordinate measuring machines with optics, probe, computed tomography and multi-sensor systems

The operation of machines with a wide variety of sensors, as well as the evaluation of volume data and point clouds ...

Comprehensive service around the coordinate measuring machine

Services from initial commissioning, training and maintenance to retrofitting ...
